室内小间距系列技术参数indoor small spacing series technical parameters |
| 产品型号Model Number |
p1.5625 |
p1.667 |
P1.875 |
P1.923 |
P2.0 |
| 模组Unit Module |
模组尺寸Module size |
200mm*100mm |
120*120 |
200*100 |
192*96 |
| 物理点间距Pixel pitch |
1.5625mm |
1.667mm |
1.875mm |
1.923mm |
2.0mm |
| LED封装Package mode |
SMD1010 |
| 模组分别率Pixel resolution |
128*64 |
120*60 |
64*64 |
104*52 |
96*48 |
| 扫描方式Scan mode |
1/32S |
1/30S |
1/32S |
1/26S |
1/24S |
| 白平衡亮度Brightness of white balance |
800-1000cd/m2 |
| LED屏机箱Cabinet |
箱体尺寸cabinet size |
400*300 |
480*480 |
400*300 |
576*576 |
| 箱体材质cabinet Material |
压铸铝die-casting aluminum |
| 箱体分辨率Pixel per cabinet |
256*192 |
240*180 |
256*256 |
208*156 |
288*288 |
| 箱体体厚度Thickness |
75mm |
| 整屏 |
物理密度Pixels Density(dots/m2) |
409600 |
359856 |
284444 |
270422 |
250000 |
| 最佳视距Best viewing distance |
≥1.5M |
≥1.5M |
≥1.5M |
≥2.0M |
≥2.0M |
| 最佳视角Best viewing angle |
160°(W) 120°(H) |
| 环境温度Temperature |
存贮storage:-35℃～+85℃ 工作working:-20℃～+50℃ |
| 相对湿度Relative humidity |
10%-95% |
| 工作电压Working voltage |
AC110～220V±10% |
| 平均功耗Average Power consumption |
200W/㎡ |
| 最大功耗Max.Power consumption |
≤900W/㎡ |
| 控制主机CPU |
Pentium4 or above P4或以上 |
| 操作系统Operation system |
WIN98/2000/NT/XP/WIN7 |
| 控制方式Control method |
同步控制Synchronization |
| 驱动器件Driving device |
Constant drive IC 恒流驱动 |
| 换帧频率Frme Rate |
≥70HZ |
| 刷新频率Refresh frequency |
≥1200HZ |
| 灰度/颜色Grey scale/colors |
4096级,可显示16.7M颜色 4096gray level/16.7M colors |
| 平均无故障时间 MTBF |
≥9000hours |
| 电源开关Power switch |
自动开关Automatic switch |
| 显示模式Display Mode |
≥800*600/1024*768/1920*1080 |
