P16户外常规屏系列技术参数P16 Outdoor conventional screen series technical parameters | |||||||
产品型号Model Number | p16 | ||||||
模组Unit Module | |||||||
模组尺寸Module size | 256*256 | ||||||
物理点间距Pixel pitch | 16mm | ||||||
LED封装Package mode | SMD3535 | ||||||
模组分别率Pixel resolution | 16*16 | ||||||
扫描方式Scan mode | 1/1S | ||||||
白平衡亮度Brightness of white balance | 6000-6500 | ||||||
LED屏机箱Cabinet | |||||||
箱体尺寸cabinet size | 1024*1024 | ||||||
箱体材质cabinet Material | 简易防水铁箱体/标准防水铁箱体 | ||||||
箱体分辨率Pixel per cabinet | 64*64 | ||||||
箱体体厚度Thickness | 120mm | ||||||
整屏 | |||||||
物理密度Pixels Density(dots/m2) | 3906 | ||||||
最佳视距Best viewing distance | ≥16M | ||||||
最佳视角Best viewing angle | 160°(W) 120°(H) | ||||||
环境温度Temperature |
存贮storage:-35℃~+85℃ 工作working:-20℃~+50℃ |
||||||
相对湿度Relative humidity | 10%-95% | ||||||
工作电压Working voltage | AC110~220V±10% | ||||||
平均功耗Average Power consumption | 200W/㎡ | ||||||
最大功耗Max.Power consumption | ≤900W/㎡ | ||||||
控制主机CPU | Pentium4 or above P4或以上 | ||||||
操作系统Operation system | WIN98/2000/NT/XP/WIN7 | ||||||
控制方式Control method | 同步控制Synchronization | ||||||
驱动器件Driving device | Constant drive IC 恒流驱动 | ||||||
换帧频率Frme Rate | ≥70HZ | ||||||
刷新频率Refresh frequency | ≥1200HZ | ||||||
灰度/颜色Grey scale/colors |
4096级,可显示16.7M颜色 4096gray level/16.7M colors |
||||||
平均无故障时间 MTBF | ≥9000hours | ||||||
电源开关Power switch | 自动开关Automatic switch | ||||||
显示模式Display Mode | ≥800*600/1024*768/1920*1080 |
