P3-16 s interior normal screen
Code: JL-P3-16S
Sketch:Manufacturer to supply special P4 indoor full color LED electronic display/module
Model Number p3-16S
Unit Module
Module size 192*192
Pixel pitch 3mm
LEDPackage mode SMD2121
Pixel resolution 64*64
跽Scan mode  1/16S
Brightness of white balance 1600-2000cd/m2
cabinet size 768*768
cabinet Material die-casting aluminum
Pixel per cabinet 256*256
Thickness 75mm
Pixels Density(dots/m2) 111111
Best viewing distance 2.5M
Best viewing angle  160(W) 120(H)
Temperature storage:-35桫+85                                  working:-20桫+50
Relative humidity 10%-95%
Working voltage AC110220V10%
Average Power consumption 200W/O
Max.Power consumption 900W/O
CPU Pentium4 or above P4
Operation system WIN98/2000/NT/XP/WIN7
Control method Synchronization
Driving device Constant drive IC
Frme Rate 70HZ
Refresh frequency 1200HZ
/Grey scale/colors 4096,16.7M                            4096gray level/16.7M colors
 MTBF 9000hours
Power switch Automatic switch
Display Mode 800*600/1024*768/1920*1080
